XLCT
MODEL 2XLCT
PART NUMBER DESCRIPTION
XLCT-02-01 HOUSING
XLCT-02-01-C HOUSING 360x360 SERIES
XLCT-02-02 END CAP
XLCT-02-03 PISTON
XLCT-02-04 PISTON ROD W/ROD END
XLCT-02-05 ROD END
XLCT-02-06 PISTON ROD ASSY
XLCT-02-07 CYLINDER END CAP SCREWS
XLCT-02-08 FIXED PIN UPPER
XLCT-02-09 FIXED PIN SET SCREW
XLCT-02-10 LINK RETAINING PIN SHORT
XLCT-02-11 LINK PIN LONG
XLCT-02-11-A 2XLCT ALCO LONG PIN
XLCT-02-12 LIN RETAINER SCREW
XLCT-02-13 SEAL KIT
XLCT-02-14 HEX LINK REACTION PAD
XLCT-02-15 SQ DRIVE HOUSING
XLCT-02-16 SQ DRIVE REACTION ARM
XLCT-02-17 REACTION ARM SPLINE BUSHING
XLCT-02-18 3/4" SQ DRIVE
XLCT-02-19 SQ DRIVE SET SCREW
XLCT-02-20 DRIVE RETAINER ASSY
XLCT-02-22 DRIVE PAWL PRIMARY
XLCT-02-23 DRIVE PAWL SECONDARY
XLCT-02-24 DR PAWL SOCKET HEAD E/C SCREW
XLCT-02-25 DRIVE PAWL LEAF SPRING
XLCT-02-26 LEAF SPRING SCREW
XLCT-02-27 DRIVE PAWL COIL SPRING
XLCT-02-27HX 2XLCT DR PWL SPRING HEX
XLCT-02-27SQ DRIVE PAWL COIL SPRING
XLCT-02-28 012 RATCHET 3/4"
XLCT-02-28 014 RATCHET 7/8"
XLCT-02-28 015 RATCHET 15/16"
XLCT-02-28 100 RATCHET 1"
XLCT-02-28 101 RATCHET 1-1/16"
XLCT-02-28 102 RATCHET 1-1/8"
XLCT-02-28 103 RATCHET 1-3/16"
XLCT-02-28 104 RATCHET 1-1/4"
XLCT-02-28 105 RATCHET 1-5/16"
XLCT-02-28 105MM 2XLCT RATCHET 105MM
XLCT-02-28 106 RATCHET 1-3/8"
XLCT-02-28 107 RATCHET 1-7/16"
XLCT-02-28 108 2XLCT 1-1/2" RATCHET
XLCT-02-28 109 RATCHET 1-9/16"
XLCT-02-28 110 RATCHET 1-5/8"
XLCT-02-28 111 RATCHET 1-11/16"
XLCT-02-28 112 RATCHET 1-3/4"
XLCT-02-28 113 RATCHET 1-13/16"
XLCT-02-28 114 RATCHET 1-1-7/8"
XLCT-02-28 115 RATCHET 1-15/16"
XLCT-02-28 200 RATCHET 2"
XLCT-02-28 201 RATCHET 2-1/16"
XLCT-02-28 202 RATCHET 2-1/8"
XLCT-02-28 203 RATCHET 2-3/16"
XLCT-02-28 204 RATCHET 2-1/4"
XLCT-02-28 205 RATCHET 2-5/16"
XLCT-02-28 206 RATCHET 2-3/8"
XLCT-02-28 209 2XLCT RATCHET 2-9/16"
XLCT-02-28 22MM RATCHET 22MM
XLCT-02-28 24MM RATCHET 24MM
XLCT-02-28 27MM RATCHET 27MM
XLCT-02-28 30MM 2XLCT 30MM RATCHET
XLCT-02-28 32MM RATCHET 32MM
XLCT-02-28 36MM 2XLCT 36MM RATCHET
XLCT-02-28 41MM RATCHET 41MM
XLCT-02-28 46MM RATCHET 46MM
XLCT-02-28 50MM RATCHET 50MM
XLCT-02-28 55MM RATCHET 55MM
XLCT-02-28 60MM RATCHET 60MM
XLCT-02-28SQ SQ DRIVE RATCHET
XLCT-02-29 RATCHET RETAINING PIN
XLCT-02-30 RATCHET RING ROLL PIN
XLCT-02-31 SPRING SAVER
XLCT-02-32 SPRING SPACER ROLL PIN
XLCT-02-33 DRIVE PIN
XLCT-02-33-A 2XLCT DRIVE PIN SERIES
XLCT-02-34 DRIVE PIN SPRING
XLCT-02-35L1 L/DR. PL 3/4-1/18 - 19-27
XLCT-02-35L2 L/DR. PL 1-13/16-1-1/4 - 28-32
XLCT-02-35L3 L/DR. PL 1-5/16-1-7/16 - 33-36
XLCT-02-35L4 L/DR. PL 1-1/2-1-5/8 - 37-41
XLCT-02-35L5 L/DR. PL 1-11/16-1-13/16 -42-4
XLCT-02-35L6 L/DR. PL 1-7/8-2 - 47-50
XLCT-02-35L7 L/DR. PL 2-1/16-2-3/16 - 51-55
XLCT-02-35L8 L/DR. PL 2-1/4-2-3/8 -56-60
XLCT-02-35L9 2XLCT DRIVE PLATE LEFT
XLCT-02-35R1 R/DR. PL 3/4-1/18 - 19-27
XLCT-02-35R2 R/DR. PL 1-13/16-1-1/4 - 28-32
XLCT-02-35R3 R/DR. PL 1-5/16-1-7/16 - 33-36
XLCT-02-35R4 R/DR. PL 1-1/2-1-5/8 - 37-41
XLCT-02-35R5 R/DR. PL 1-11/16-1-13/16 -42-4
XLCT-02-35R6 R/DR. PL 1-7/8-2 - 47-50
XLCT-02-35R7 R/DR. PL 2-1/16-2-3/16 - 51-55
XLCT-02-35R8 R/DR. PL 2-1/4-2-3/8 -56-60
XLCT-02-35R9 2XLCT DRIVE PLATE RIGHT
XLCT-02-35SQ DRIVE PLATE SQ
XLCT-02-36 1 REAC. PAWL
XLCT-02-36 2 REAC. PAWL
XLCT-02-36 3 REAC. PAWL
XLCT-02-36 4 REAC. PAWL
XLCT-02-36 5 REAC. PAWL
XLCT-02-36 6 REAC. PAWL
XLCT-02-36 7 REAC. PAWL
XLCT-02-36 8 REAC. PAWL
XLCT-02-36SQ REACTION PAWL
XLCT-02-37 2XLCT REAC. PWL SPRING
XLCT-02-37SQ REACTION PAWL SPRING
XLCT-02-38SQ REACTION PAWL SPRING ROLL PIN
XLCT-02-39SQ REACTION PAWL SPRING DOWEL PIN
XLCT-02-40 DISENGAGEMENT LEVER ASSY
XLCT-02-41 LEVER SCREW
XLCT-02-42 DRIVE PLATE STOP PIN
XLCT-02-43 1 SHROUD 3/4 -1-1/8,19-27"
XLCT-02-43 2 SHROUD 1-3/16-1-1/4,28-32"
XLCT-02-43 3 SHROUD 1-5/16-1-7/16,33-36"
XLCT-02-43 4 SHROUD 1-1/2-1-5/8, 37-41"
XLCT-02-43 5 SHROUD 1-11/16-1-13/16,42-46"
XLCT-02-43 6 SHROUD 1-7/8-2,47/50"
XLCT-02-43 7 SHROUD 2-1/16-2-3/16,51-55"
XLCT-02-43 8 SHROUD 2-1/4-2-3/8,56-60"
XLCT-02-43 9 2XLCT SHROUD #9
XLCT-02-43SQ SHROUD
XLCT-02-44 HX SHROUD SCREW/HEX LINK
XLCT-02-44SQ SHROUD SCREW
XLCT-02-45 REACTION BLOCK SPACER
XLCT-02-45-7 2XLCT REACTION PAD SPACER #7
XLCT-02-45-C REACTION BLOCK SPACER
XLCT-02-46 TOP SPACER
XLCT-02-47 REACTION PAWL SPRING SPACER
XLCT-02-48 SIDE PLATE ROLL PIN
XLCT-02-49 SPRING SEAT
XLCT-02-50 SIDE PLATE SCREW BOTTOM
XLCT-02-51 SIDE PLATE SCREW TOP
XLCT-02-52L 1 SIDE PLATE LT 3/4-1-1/8,19-27
XLCT-02-52L 2 SIDE PLATE LT 1-3/16-1-1/4,
XLCT-02-52L 3 SIDE PLATE LEFT 1-5/16-1-7/16
XLCT-02-52L 4 SIDE PLATE LEFT 1-1/2-1-5/8,3
XLCT-02-52L 5 SIDE PLATE LT 1-11/16-1-13/16
XLCT-02-52L 6 SIDE PLATE LEFT 1-7/8-2,47-50
XLCT-02-52L 7 SIDE PLATE LEFT 2-1/16-2-3/16
XLCT-02-52L 8 SIDE PLATE LEFT 2-1/4-2-3/8,5
XLCT-02-52L 9 2XLCT SDE PLT LFT 2-3/1"
XLCT-02-52R 1 SIDE PLATE RIGHT 3/4-1-1/8,19
XLCT-02-52R 2 SIDE PLATE RIGHT 1-3/16-1-1/4
XLCT-02-52R 3 SIDE PLATE RIGHT 1-5/16-1-7/1
XLCT-02-52R 4 SIDE PLATE RIGHT 1-1/2-1-5/8,
XLCT-02-52R 5 SIDE PLATE RIGHT 1-11/16-1-13
XLCT-02-52R 6 SIDE PLATE RIGHT 1-7/8-2,47-5
XLCT-02-52R 7 SIDE PLATE RIGHT 2-1/16-2-3/1
XLCT-02-52R 8 SIDE PLATE RIGHT 2-1/4-2-3/8,
XLCT-02-52R 9 2XLCT SDE PLT RGHT 2-13/
XLCT-02-60C 2XLCT END CAP POST
XLCT-02-61C 2XLCT SWIVEL POST
XLCT-02-62 UNISWIVEL ASSY 360x360
XLCT-02-63 UNISWIVEL 360x360 SEAL KIT
XLCT-02-64 2XLCT BUSH HOUSING
XLCT-02-65 2XLCT BUSH HOUSING


Y-NPL-XLCT NAME PLATE XLCT
Y-XLT-SF011 1XLT UNISWIVEL POST
Y-XLT-SF012 1XLT/2XLCT UNISWIVEL BL
Y-XLT-SF013 1XLT UNISWIVEL SAFETY SHIELD
Y-XLT-SF014 1XLT/2XLCT RET RING UNI


MK-HY-2XLCT 2XLCT MAINT KIT
MODEL 4XLCT
PART NUMBER DESCRIPTION
XLCT-04-01 HOUSING
XLCT-04-01-C HOUSING 360 X 360 SERIES
XLCT-04-02 END CAP
XLCT-04-03 PISTON
XLCT-04-04 PISTON ROD W/ ROD END
XLCT-04-04 NS 4XLCT PISTON ROD NEW ST
XLCT-04-05 4XLCT ROD END
XLCT-04-06 PISTON ROD ASSY
XLCT-04-07 CYLINDER END CAP SCREWS
XLCT-04-08 FIXED PIN UPPER
XLCT-04-09 FIXED PIN SET SCREW
XLCT-04-10 LINK PIN SHORT
XLCT-04-11 LINK PIN LONG
XLCT-04-11-1 4XLCT REACTION PAD PIN
XLCT-04-11-A 4XLCT ALCO LONG PIN
XLCT-04-12 LINK PIN RETAINER
XLCT-04-13 SEAL KIT
XLCT-04-14 HEX LINK REACTION PAD
XLCT-04-15 SQ.DR. HOUSING
XLCT-04-16 SQ.DR. REACTION SRM
XLCT-04-17 REACTION ARM SPLINE BUSHING
XLCT-04-18 SQ. DRIVE 3/4"
XLCT-04-19 SQ. DRIVE SET SCREW
XLCT-04-20 DRIVE RETAINER ASSY
XLCT-04-22 DRIVE PAWL PRIMARY
XLCT-04-23 DRIVE PAWL SECONDARY
XLCT-04-24 DRIVE PAWL SOCKET HEAD CAP SCR
XLCT-04-25 DRIVE PAWL LEAF SPRING
XLCT-04-26 LEAF SPRING SCREW
XLCT-04-27 DRIVE PAWL COIL SPRING
XLCT-04-27 HX DRIVE PAWL SPRING HEW LINK
XLCT-04-28-27MM 4XLCT RATCHET 27MM
XLCT-04-28-32MM 32MM RATCHET
XLCT-04-28-36MM 36MM RATCHET
XLCT-04-28-41MM 41MM RATCHET
XLCT-04-28-46MM 46MM RATCHET
XLCT-04-28-50MM 50MM RATCHET
XLCT-04-28-55MM 55MM RATCHET
XLCT-04-28-60MM 60MM RATCHET
XLCT-04-28-65MM 65MM RATCHET
XLCT-04-28-70MM 70MM RATCHET
XLCT-04-28-75MM 75MM RATCHET
XLCT-04-28-80MM 80MM RATCHET
XLCT-04-28 100 4XLCT RATCHET 1"
XLCT-04-28 105 RATCHET 1-5/16"
XLCT-04-28 106 RATCHET 1-3/8"
XLCT-04-28 107 RATCHET 1-7/16"
XLCT-04-28 108 RATCHET 1-1/2"
XLCT-04-28 109 RATCHET 1-9/16"
XLCT-04-28 110 RATCHET 1-5/8"
XLCT-04-28 111 RATCHET 1-11/16"
XLCT-04-28 112 RATCHET 1-3/4"
XLCT-04-28 113 RATCHET 1-13/16"
XLCT-04-28 114 RATCHET 1-7/8"
XLCT-04-28 115 RATCHET 1-15/16"
XLCT-04-28 200 RATCHET 2"
XLCT-04-28 201 RATCHET 2-1/16"
XLCT-04-28 202 RATCHET 2-1/8"
XLCT-04-28 203 RATCHET 2-3/16"
XLCT-04-28 204 RATCHET 2-1/4"
XLCT-04-28 205 RATCHET 2-5/16"
XLCT-04-28 206 RATCHET 2-3/8"
XLCT-04-28 207 RATCHET 2-7/16"
XLCT-04-28 208 RATCHET 2-1/2"
XLCT-04-28 209 RATCHET 2-9/16"
XLCT-04-28 210 RATCHET 2-5/8"
XLCT-04-28 211 RATCHET 2-11/16"
XLCT-04-28 212 RATCHET 2-3/4''
XLCT-04-28 213 RATCHET 2-13/16"
XLCT-04-28 214 RATCHET 2-7/8"
XLCT-04-28 215 RATCHET 2-15/16"
XLCT-04-28 300 RATCHET 3"
XLCT-04-28 301 RATCHET 3-1/16"
XLCT-04-28 302 RATCHET 3-1/8"
XLCT-04-28 SQ SQ. DRIVE RATCHET
XLCT-04-29 RATCHET RETAINING PIN
XLCT-04-30 RATCHET RING ROLL PIN
XLCT-04-31 SPRING SPACER
XLCT-04-32 SPRING SPACER ROLL PIN
XLCT-04-33 DRIVE PIN
XLCT-04-34 DRIVE PIN SPRING
XLCT-04-35 SQ DRIVE PLATE SQ.
XLCT-04-35L 1 LEFT DRIVE PLATE 1-5/16-1-7/1
XLCT-04-35L 10 LEFT DRIVE PLATE 3-3-1/8,76-8
XLCT-04-35L 2 LEFT DRIVE PLATE 1-1/2-1-5/8,
XLCT-04-35L 3 LEFT DRIVE PLATE 1-11/16-1-13
XLCT-04-35L 4 LEFT DRIVE PLATE 1-7/8-2,47-5
XLCT-04-35L 5 LEFT DRIVE PLATE 1-1/16-2-3/1
XLCT-04-35L 6 LEFT DRIVE PLATE 2-1/4-2-3/8,
XLCT-04-35L 7 LEFT DRIVE PLATE 2-7/16-2-9/1
XLCT-04-35L 8 LEFT DRIVE PLATE 2-5/8-2-3/4,
XLCT-04-35L 9 LEFT DRIVE PLATE 2-13/16-2-15
XLCT-04-35R 1 RIGHT DRIVE PLATE 1-5/16-1-71
XLCT-04-35R 10 RIGHT DRIVE PLATE 3-3-1/8,76-
XLCT-04-35R 2 RIGHT DRIVE PLATE 1-1/2-1-5/8
XLCT-04-35R 3 RIGHT DRIVE PLATE 1-11/16-1-1
XLCT-04-35R 4 RIGHT DRIVE PLATE 1-7/8-2,47-
XLCT-04-35R 5 RIGHT DRIVE PLATE 2-1/16-2-3/
XLCT-04-35R 6 RIGHT DRIVE PLATE 2-1/4-2-3/8
XLCT-04-35R 7 RIGHT DRIVE PLATE 2-7/16-2-9/
XLCT-04-35R 8 RIGHT DRIVE PLATE 2-5/8-2-3/4
XLCT-04-35R 9 RIGHT DRIVE PLATE 2-13/16-2-1
XLCT-04-36 1 REAC. PAWL 1-5/16-1-7/16.34-36
XLCT-04-36 10 REAC. PAWL 3-3-1/8,76-80"
XLCT-04-36 2 REAC. PAWL 1-1/2-1-5/8.37-41
XLCT-04-36 3 REAC. PAWL 1-11/16-1-13/16,42
XLCT-04-36 4 REAC. PAWL 1-7/8-2,47-50"
XLCT-04-36 5 REAC. PAWL 2-1/16-2-3/16,51-5
XLCT-04-36 6 REAC. PAWL 2-1/4-2-3/8,56-60"
XLCT-04-36 7 REAC. PAWL 2-7/16-2-9/16,61-6
XLCT-04-36 8 REAC. PAWL 2-5/8-2-3/4,66-70"
XLCT-04-36 9 REAC. PAWL 2-13/16-0-15/16,71
XLCT-04-36 SQ REACTION PAWL
XLCT-04-37 REACTION PAWL SPRING HEX LINK
XLCT-04-37 HX 4XLCT RCT PWL SPR HEX L
XLCT-04-37 SQ REACTION PAWL SPRING
XLCT-04-38 SQ REACTION PAWL SPRING ROLL PIN
XLCT-04-39 SQ REACTION PAWL SPR DOWEL PIN
XLCT-04-40 DISENGAGEMENT LEVER ASSY
XLCT-04-41 LEVER SCREW
XLCT-04-42 DRIVE PLATE STOP PIN
XLCT-04-43 1 SHROUD 1-5/16-1-7/16,34-36
XLCT-04-43 10 SHROUD 3-3-1/8,76-80"
XLCT-04-43 2 SHROUD 1-1/2-1-5/8,37-41"
XLCT-04-43 3 SHROUD 1-11/16-1-13/16,42-46"
XLCT-04-43 4 SHROUD 1-7/8-2,47-50"
XLCT-04-43 5 SHROUD 2-1/16-2-3/16,51-55"
XLCT-04-43 6 SHROUD 2-1/4-2-3/8,56-60"
XLCT-04-43 7 SHROUD 2-7/16-2-9/16,61-65"
XLCT-04-43 8 SHROUD 2-5/8-2-3/3,66-70"
XLCT-04-43 9 SHROUD 2-13/16-2-15/16,71-75"
XLCT-04-43 SQ SHROUD
XLCT-04-44 HX SHROUD SCREW HEX LINK
XLCT-04-44 SQ SHROUD SCREW
XLCT-04-45 REACTION BLOCK SPACER
XLCT-04-45-C REACTION BLOCK SPACER EXTENDED
XLCT-04-46 4XLCT TOP SPACER
XLCT-04-47 4XLCT REAC. PAWL SPRING
XLCT-04-48 4XLCT SIDE PLATE ROLL P
XLCT-04-49 4XLCT D/PAWL SPRING SEA
XLCT-04-50 4XLCT SIDE PLATE SCREW
XLCT-04-51 4XLCT SIDE PLATE SCREW
XLCT-04-52L 1 SIDE PLATE LEFT 1-5/16-1-7/16
XLCT-04-52L 10 SIDE PLATE LEFT 3-3-1/8,76-80
XLCT-04-52L 2 SIDE PLATE LEFT 1-1/2-1-5/8,3
XLCT-04-52L 3 SIDE PLATE LEFT 1-11/16-1-13/
XLCT-04-52L 4 SIDE PLATE LEFT 1-7/8-2,47-50
XLCT-04-52L 5 SIDE PLATE LEFT 2-1/16-2-3/16
XLCT-04-52L 6 SIDE PLATE LEFT 2-1/4-2-3/8,5
XLCT-04-52L 7 SIDE PLATE LEFT 2-7/16-2-9/16
XLCT-04-52L 8 SIDE PLATE LEFT 2-5/8-2-3/4,6
XLCT-04-52L 9 SIDE PLATE LEFT 2-13/16-2-15/
XLCT-04-52R 1 SIDE PLATE RIGHT 1-5/16-1-7/1
XLCT-04-52R 10 SIDE PLATE RIGHT 3-3-1/8,76-8
XLCT-04-52R 2 SIDE PLATE RIGHT 1-1/2-1-5/8,
XLCT-04-52R 3 SIDE PLATE RIGHT 1-11/16-1-13
XLCT-04-52R 4 SIDE PLATE RIGHT 1-7/8-2,47-5
XLCT-04-52R 5 SIDE PLATE RIGHT 2-1/16-2-3/1
XLCT-04-52R 6 SIDE PLATE RIGHT 2-1/4-2-3/8,
XLCT-04-52R 7 SIDE PLATE RIGHT 2-7/16-2-9/1
XLCT-04-52R 8 SIDE PLATE RIGHT 2-5/8-2-3/4,
XLCT-04-52R 9 SIDE PLATE RIGHT 2-13/16-2-15
XLCT-04-54 SPLINE BRUSHING
XLCT-04-60-C 4XLCT END CAP POST
XLCT-04-61-C 4XLCT SWIVEL POST
XLCT-04-62 UNISWIVEL ASY 360X360
XLCT-04-63 UNISWIVEL 360X360 SEAL KIT
XLCT-04-64 CIRCLIP
XLCT-04-65 4XLCT BUSH HOUSING


Y-NPL-XLCT NAME PLATE XLCT
Y-XLT-SF001 3-25XLT UNISWIVEL POST
Y-XLT-SF002 3-25XLT SWIV BLOCK
Y-XLT-SF003 3-25XLT SAFETY SHIELD
MODEL 8XLCT
PART NUMBER DESCRIPTION
XLCT-08-01 HOUSING
XLCT-08-01-C HOUSING 360 X 360 SERIES
XLCT-08-02 END CAP
XLCT-08-03 PISTON
XLCT-08-04 PISTON ROD
XLCT-08-05 ROD END
XLCT-08-06 PISTON ROD ASSY
XLCT-08-07 CYLINDER END CAP SCREWS
XLCT-08-08 FIXED PIN UPPER
XLCT-08-09 FIXED PIN SET SCREW
XLCT-08-10 LINK PIN SHORT
XLCT-08-11 LINK PIN LONG
XLCT-08-11-1 8XLCT REACTION PAD PINS
XLCT-08-11-A 8XLCT ALCO LONG PIN
XLCT-08-12 LINK PIN RETAINER
XLCT-08-13 SEAL KIT
XLCT-08-14 HEX LINK REACTION PAD
XLCT-08-15 SQ. DR. HOUSING
XLCT-08-16 SQ. DR. REACTION ARM
XLCT-08-17 REACTION ARM SPLINE BUSHING
XLCT-08-18 3/4" SQ. DRIVE
XLCT-08-19 SQ. DRIVE SET SCREW
XLCT-08-20 DRIVE RETAINER ASSY
XLCT-08-22 DRIVE PAWL PRIMARY
XLCT-08-23 DRIVE PAWL SECONDARY
XLCT-08-24 DRIVE PAWL SOCKET HEAD CAP SCR
XLCT-08-25 DRIVE PAWL LEAF SPRING
XLCT-08-26 LEAF SPRING SCREW
XLCT-08-27 DRIVE PAWL SPRING
XLCT-08-27 HX 8XLCT DRIVE PAWL SPRING
XLCT-08-27 SQ DRIVE PAWL COIL SPRING
XLCT-08-28 100MM 100MM RATCHET
XLCT-08-28 105 105MM RATCHET
XLCT-08-28 108 1-1/2" RATCHET
XLCT-08-28 109 1-9/16" RATCHET
XLCT-08-28 110 1-5/8" RATCHET
XLCT-08-28 110D 8XLCT 1-5/8" RATCHET 12
XLCT-08-28 111 1-11/16" RATCHET
XLCT-08-28 112 1-3/4" RATCHET
XLCT-08-28 113 1-13/16" RATCHET
XLCT-08-28 114 1-7/8" RATCHET
XLCT-08-28 115 1-15/16" RATCHET
XLCT-08-28 200 2" RATCHET
XLCT-08-28 200D 8XLCT RATCHET 2" 12 POINT
XLCT-08-28 201 2-1/16" RATCHET
XLCT-08-28 202 2-1/8" RATCHET
XLCT-08-28 203 2-3/16" RATCHET
XLCT-08-28 204 2-1/4" RATCHET
XLCT-08-28 205 2-5/16" RATCHET
XLCT-08-28 206 2-3/8" RATCHET
XLCT-08-28 207 2-7/16" RATCHET
XLCT-08-28 208 2-1/2" RATCHET
XLCT-08-28 209 2-9/16" RATCHET
XLCT-08-28 210 2-5/8" RATCHET
XLCT-08-28 211 2-11/16" RATCHET
XLCT-08-28 212 2-3/4" RATCHET
XLCT-08-28 212D RATCHET 2-3/4" 12 POINT
XLCT-08-28 213 2-13/16" RATCHET
XLCT-08-28 214 2-7/8" RATCHET
XLCT-08-28 215 2-15/16" RATCHET
XLCT-08-28 300 3" RATCHET
XLCT-08-28 301 3-1/16" RATCHET
XLCT-08-28 302 3-1/8" RATCHET
XLCT-08-28 303 3-3/16" RATCHET
XLCT-08-28 304 3-1/4" RATCHET
XLCT-08-28 305 3-5/16" RATCHET
XLCT-08-28 306 3-3/8" RATCHET
XLCT-08-28 307 3-7/16" RATCHET
XLCT-08-28 308 3-1/2" RATCHET
XLCT-08-28 309 3-9/16" RATCHET
XLCT-08-28 310 3-5/8" RATCHET
XLCT-08-28 311 3-11/16" RATCHET
XLCT-08-28 312 3-3/4" RATCHET
XLCT-08-28 313 3-3/16" RATCHET
XLCT-08-28 314 3-7/8" RATCHET
XLCT-08-28 400 8XLCT 4" RATCHET
XLCT-08-28 41MM 41MM RATCHET
XLCT-08-28 46MM 46MM RATCHET
XLCT-08-28 50MM 50MM RATCHET
XLCT-08-28 55MM 55MM RATCHET
XLCT-08-28 60MM 60MM RATCHET
XLCT-08-28 65MM 65MM RATCHET
XLCT-08-28 70MM 70MM RATCHET
XLCT-08-28 75MM 75MM RATCHET
XLCT-08-28 80MM 80MM RATCHET
XLCT-08-28 85MM 85MM RATCHET
XLCT-08-28 90MM 90MM RATCHET
XLCT-08-28 95MM 95MM RATCHET
XLCT-08-28 SQ SQ. DRIVE RATCHET
XLCT-08-29 RATCHET RETAINING PIN
XLCT-08-30 RATCHET RING ROLL PIN
XLCT-08-31 SPRING SPACER
XLCT-08-32 SPRING SPACER ROLL PIN
XLCT-08-33 DRIVE PIN
XLCT-08-34 DRIVE PIN SPRING
XLCT-08-35 SQ DRIVE PLATE SQ.
XLCT-08-35L 1 L/DR PL 1-1/2 - 2, 38-50
XLCT-08-35L 10 L/DR PL 3-9/16 3-3/4, 91-95"
XLCT-08-35L 11 L/DR PL 3-13/16 3-7/8, 96-100
XLCT-08-35L 2 L/DR PL 2-1/16 2-3/16, 51-55
XLCT-08-35L 3 L/DR PL 2-1/4 2-3/8, 56-60
XLCT-08-35L 4 L/DR PL 2-7/16 2-9/16, 61-65
XLCT-08-35L 5 L/DR PL 2-5/8 2-3/4, 66-70
XLCT-08-35L 6 L/DR PL 2-13/16 2-15/16, 71-75
XLCT-08-35L 7 L/DR PL 3 - 3-1/8, 76-80
XLCT-08-35L 8 L/DR PL 3-3/16 3-3/8, 81-85"
XLCT-08-35L 9 L/DR PL 3-7/16 3-1/2, 86-90"
XLCT-08-35R 1 R/DR PL 1-1/2 - 2, 38-50"
XLCT-08-35R 10 R/DR PL 3-9/16 3-3/4, 91-95"
XLCT-08-35R 11 R/DR PL 3-13/16 3-7/8, 96-100
XLCT-08-35R 2 R/DR PL 2-1/16 2-3/16, 51-55"
XLCT-08-35R 3 R/DR PL 2-1/4 2-3/8, 56-60"
XLCT-08-35R 4 R/DR PL 2-7/16 2-9/16, 61-65"
XLCT-08-35R 5 R/DR PL 2-5/8 2-3/4, 66-70"
XLCT-08-35R 6 R/DR PL 2-13/16 2-15/16, 71-7
XLCT-08-35R 7 R/DR PL 3, 3/18, 76-80"
XLCT-08-35R 8 R/DR PL 3-3/16 3-3/8, 81-85"
XLCT-08-35R 9 R/DR PL 3-7/16 3-1/2, 86-90"
XLCT-08-36 1 REAC. PAWL 1-1/2 2, 38-50"
XLCT-08-36 10 REAC. PAWL 3-9/16 3-3/4, 91-9
XLCT-08-36 11 REAC. PAWL 3-13/16 3-7/8, 96-
XLCT-08-36 2 REAC. PAWL 2-1/16 2-3/16, 51-
XLCT-08-36 3 REAC. PAWL 2-1/4 2-3/8, 56-60
XLCT-08-36 4 REAC. PAWL 2-7/16 2-9/16, 61-
XLCT-08-36 5 REAC. PAWL 2-5/8 2-3/4, 66-70
XLCT-08-36 6 REAC. PAWL 2-13/16 2-15/16, 7
XLCT-08-36 7 REAC. PAWL 3, 3-1/8, 76-80"
XLCT-08-36 8 REAC. PAWL 3-3/16 3-3/8, 81-8
XLCT-08-36 9 REAC. PAWL 3-7/16 3-1/2, 86-9
XLCT-08-36 SQ REACTION PAWL
XLCT-08-37 REAC. PAWL SPRING HEW LINK
XLCT-08-37 HX 8XLCT RCT PWL SPRING HEX
XLCT-08-37 SQ REACTION PAWL SPRING
XLCT-08-38 SQ REACTION PAWL SPRING ROLL PIN
XLCT-08-39 SQ REACTION PWL SPRING DOWEL PIN
XLCT-08-40 DISENGAGEMENT LEVEL ASSY
XLCT-08-41 LEVER SCREW
XLCT-08-42 DRIVE PLATE STOP PIN
XLCT-08-43 1 SHROUD 1-1/2 2, 38-50
XLCT-08-43 10 SHROUD 3-9/16 3-3/4, 91-95
XLCT-08-43 11 SHROUD 3-13/16 3-7/8, 96-100
XLCT-08-43 12 SHROUD #12 105MM
XLCT-08-43 2 SHROUD 2-1/16 2-3/16, 51-55
XLCT-08-43 3 SHROUD 2-1/4 2-3/8, 56-60
XLCT-08-43 4 SHROUD 2-7/16 2-9/16, 61-65
XLCT-08-43 5 SHROUD 2-5/8 2-3/4, 66-70
XLCT-08-43 6 SHROUD 2-13/16 2-15/16, 71-75
XLCT-08-43 7 SHROUD 3, 3-1/8, 76-80
XLCT-08-43 8 SHROUD 3-3/16 3-3/8, 81-85
XLCT-08-43 9 SHROUD 3-7/16 3-1/2, 86-90
XLCT-08-43 SQ SHROUD
XLCT-08-44 HX SHROUD SCREW/HEX LINK
XLCT-08-44 SQ SHROUD SCREW
XLCT-08-45 REACTION BLOCK SPACER
XLCT-08-45-C REACTION BLOCK SPACER EXTENDED
XLCT-08-46 TOP SPACER
XLCT-08-47 REACTION PAWL SPRING SPACER
XLCT-08-48 SIDE PLATE ROLL PIN
XLCT-08-49 SPRING SEAT
XLCT-08-50 SIDE PLATE SCREW BOTTOM
XLCT-08-51 SIDE PLATE SCREW TOP
XLCT-08-52L 1 SIDE PL/LEFT 1-1/2 2, 38-50"
XLCT-08-52L 10 SIDE PL/LEFT 3-9/16 3-3/4, 91
XLCT-08-52L 11 SIDE PL/LEFT 3-13/16 33-7/8,
XLCT-08-52L 2 SIDE PL/LEFT 2-1/16 2-3/16, 5
XLCT-08-52L 3 SIDE PL/LEFT 2-1/4 2-3/8, 56-
XLCT-08-52L 4 SIDE PLATE LEFT
XLCT-08-52L 5 SIDE PL/LEFT 2-5/8 2-3/4, 66-
XLCT-08-52L 6 SIDE PL/LEFT 2-13/16 2-15/16,
XLCT-08-52L 7 SIDE PL/LEFT 3, 3-1/8, 76-80"
XLCT-08-52L 8 SIDE PL/LEFT 3-3/16 33-3/8, 8
XLCT-08-52L 9 SIDE PL/LEFT 3-7/16 3-1/2, 86
XLCT-08-52R 1 SIDE PL/RIGHT 1-1/2 2, 38-50"
XLCT-08-52R 10 SIDE PL/RIGHT 3-9/16 3-3/4, 9
XLCT-08-52R 11 SIDE PL/RIGHT 3-13/16 3-7/8,
XLCT-08-52R 2 SIDE PL/RIGHT 2-1/16 2-3/16,
XLCT-08-52R 3 SIDE PL/RIGHT 2-1/4 2-3/8, 56
XLCT-08-52R 4 SIDE PL/RIGHT 2-7/16 2-9/16,
XLCT-08-52R 5 SIDE PL/RIGHT 2-5/8 2-3/4, 66
XLCT-08-52R 6 SIDE PL/RIGHT 2-13/16 2-15/16
XLCT-08-52R 7 SIDE PL/RIGHT 3, 3-1/8, 76-80
XLCT-08-52R 8 SIDE PL/RIGHT 3-3/16 3-3/8, 8
XLCT-08-52R 9 SIDE PL/RIGHT 3-7/16 3-1/2, 8
XLCT-08-60-C 8XLCT END CAP POST
XLCT-08-61-C 8XLCT SWIVEL POST
XLCT-08-62 UNISWIVEL ASSY 360 X 360
XLCT-08-63 UNISWIVEL 360 X 360 SEAL KIT
XLCT-08-64 8XLCT BUSH HOUSING


Y-NPL-XLCT NAME PLATE XLCT
Y-XLT-SF001 3-25XLT UNISWIVEL POST
Y-XLT-SF002 3-25XLT SWIV BLOCK
Y-XLT-SF003 3-25XLT SAFETY SHIELD


MK-HY-8XLCT 8XLCT MAINT KIT
MODEL 14XLCT
PART NUMBER DESCRIPTION
XLCT-14-01 HOUSING
XLCT-14-01-C HOUSING "C" SERIES 360X360
XLCT-14-02 END CAP
XLCT-14-03 PISTON
XLCT-14-04 PISTON ROD
XLCT-14-05 ROD END
XLCT-14-05 NS 14XLCT ROD END NEW STYLE
XLCT-14-06 PISTON ROD ASSY
XLCT-14-07 CYLINDER END CAP SCREWS
XLCT-14-08 FIXED PIN UPPER
XLCT-14-09 FIXED PIN SET SCREW
XLCT-14-10 LINK PIN SHORT
XLCT-14-11 LINK PIN LONG
XLCT-14-11-1 14XLCT REACTION PAD PIN
XLCT-14-11-A 14XLCT ALCO LONG PIN
XLCT-14-12 LINK PIN RETAINER
XLCT-14-13 SEAL KIT
XLCT-14-14 HEX LINK REACTION PAD
XLCT-14-15 SQ. DR. HOUSING
XLCT-14-16 SQ. DR. REACTION ARM
XLCT-14-17 REACTION ARM SPLINE BUSHING
XLCT-14-18 SQ. DRIVE 3/4"
XLCT-14-19 SQ. DRIVE SET SCREW
XLCT-14-20 DRIVE RETAINER ASSY
XLCT-14-22 DRIVE PAWL PRIMARY
XLCT-14-23 DRIVE PAWL SECONDARY
XLCT-14-24 DRIVE PAWL SOCKET HEAD SCREW
XLCT-14-25 DRIVE PAWL LEAF SPRING
XLCT-14-26 LEAF SPRING SCREW
XLCT-14-27 DRIVE PAWL SPRING HEX LINK
XLCT-14-27 HX 14XLCT DRV PWL SPRING HEX
XLCT-14-28 100MM 100MM RATCHET
XLCT-14-28 105MM 105MM RATCHET
XLCT-14-28 110MM 110MM RATCHET
XLCT-14-28 115MM 115MM RATCHET
XLCT-14-28 120MM 120MM RATCHET
XLCT-14-28 200 RATCHET 2"
XLCT-14-28 201 RACHET 2-1/16"
XLCT-14-28 202 RACHET 2-1/8"
XLCT-14-28 203 RACHET 2-3/16"
XLCT-14-28 204 RACHET 2-1/4"
XLCT-14-28 205 RACHET 2-5/16"
XLCT-14-28 206 X RACHET 2-3/8"
XLCT-14-28 207 RACHET 2-3/8"
XLCT-14-28 208 RACHET 2-1/2"
XLCT-14-28 209 RACHET 2-9/16"
XLCT-14-28 210 RACHET 2-5/8"
XLCT-14-28 211 RACHET 2-11/16"
XLCT-14-28 212 RACHET 2-3/4"
XLCT-14-28 213 RACHET 2-13/16"
XLCT-14-28 214 RACHET 2-7/8"
XLCT-14-28 215 RACHET 2-15/16"
XLCT-14-28 300 RACHET 3"
XLCT-14-28 301 RACHET 3-1/16"
XLCT-14-28 302 RACHET 3-1/8"
XLCT-14-28 303 X RACHET 3-1/8"
XLCT-14-28 304 RACHET 3-1/4"
XLCT-14-28 305 RACHET 3-5/16"
XLCT-14-28 306 RACHET 3-3/8"
XLCT-14-28 307 RACHET 3-7/16"
XLCT-14-28 308 RATCHET 3-1/2"
XLCT-14-28 309 X RACHET 3-7/16"
XLCT-14-28 310 RACHET 3-5/8"
XLCT-14-28 311 RACHET 3-11/16"
XLCT-14-28 312 RACHET 3-3/4"
XLCT-14-28 313 RACHET 3-13/16"
XLCT-14-28 314 RACHET 3-7/8"
XLCT-14-28 315 RACHET 3-15/16"
XLCT-14-28 400 RACHET 4"
XLCT-14-28 401 RACHET 4-1/16"
XLCT-14-28 402 X RACHET 4-1/16"
XLCT-14-28 403 RACHET 4-3/16"
XLCT-14-28 404 RACHET 4-1/4"
XLCT-14-28 405 RACHET 4-5/16"
XLCT-14-28 406 RACHET 4-3/8"
XLCT-14-28 407 RACHET 4-7/16"
XLCT-14-28 408 RACHET 4-1/2"
XLCT-14-28 409 RACHET 4-9/16"
XLCT-14-28 410 RACHET 4-5/8"
XLCT-14-28 50MM 50MM RACHET
XLCT-14-28 55MM 55MM RACHET
XLCT-14-28 60MM 60MM RACHET
XLCT-14-28 65MM 65MM RACHET
XLCT-14-28 70MM 70MM RACHET
XLCT-14-28 75MM 75MM RACHET
XLCT-14-28 80MM 80MM RACHET
XLCT-14-28 85MM 85MM RACHET
XLCT-14-28 90MM 90MM RACHET
XLCT-14-28 95MM 95MM RACHET
XLCT-14-28 SQ SQ. DRIVE RATCHET
XLCT-14-29 RATCHET RETAINING PIN
XLCT-14-30 RATCHET RING ROLL PIN
XLCT-14-31 SPRING SPACER
XLCT-14-32 SPRING SPACER ROLL PIN
XLCT-14-33 DRIVE PIN
XLCT-14-34 DRIVE PIN SPRING
XLCT-14-34 NS 14XLCT DRIVE PIN SPRING
XLCT-14-35 SQ DRIVE PLATE SQ.
XLCT-14-35L 1 L/DR PL 2, 2-3/4, 50-70
XLCT-14-35L 10 L/DR PL 4-5/16 4-5/8, 111-120
XLCT-14-35L 2 L/DR PL 2-13/16 2-15/16, 71-7
XLCT-14-35L 3 L/DR PL 3, 3-1/8, 76-80
XLCT-14-35L 4 L/DR PL 3-3/16 3-3/8, 81-85
XLCT-14-35L 5 L/DR PL 3-7/16 3-1/2, 86-90
XLCT-14-35L 6 L/DR PL 3-9/16 3-3/4, 91-95
XLCT-14-35L 7 L/DR PL 3-13/16 3-7/8, 96-100
XLCT-14-35L 8 L/DR PL 3-15/16 4-1/8, 101-10
XLCT-14-35L 9 L/DR PL 4-3/16 4-1/4, 106-110
XLCT-14-35R 1 R/DR PL 2, 2-3/4, 5-70
XLCT-14-35R 10 R/DR PL 4-5/16 4-5/8, 111-120
XLCT-14-35R 2 R/DR PL 2-13/16 2-15/16, 71-7
XLCT-14-35R 3 R/DR PL 3, 3-1/8, 76-80
XLCT-14-35R 4 R/DR PL 3-3/16 3-3/8, 81-85
XLCT-14-35R 5 R/DR PL 3-7/16 3-1/2, 86-90
XLCT-14-35R 6 R/DR PL 3-9/16 3-3/4, 91-95
XLCT-14-35R 7 R/DR PL 3-13/16 3-7/8, 96-10
XLCT-14-35R 8 R/DR PL 3-15/16 4-1/8, 101-1
XLCT-14-35R 9 R/DR PL 4-3/16 4-1/4, 106-11
XLCT-14-36 1 REAC. PAWL 2, 2-3/4, 50-70
XLCT-14-36 10 REAC. PAWL 4-5/16 4-5/8, 111-
XLCT-14-36 2 REAC. PAWL 2-13/16 2-15/16, 7
XLCT-14-36 3 REAC. PAWL 3, 3-1/8, 76-80
XLCT-14-36 4 REAC. PAWL 3-3/16 3-3/8, 81-8
XLCT-14-36 5 REAC. PAWL 3-7/16 3-1/2, 86-9
XLCT-14-36 6 REAC. PAWL 3-9/16 3-3/4, 91-9
XLCT-14-36 7 REAC. PAWL 3-13/16 3-7/8, 96-
XLCT-14-36 8 REAC. PAWL 3-15/16 4-1/8, 101
XLCT-14-36 9 REAC. PAWL 4-3/16 4-1/4, 106-
XLCT-14-36 SQ REACTION PAWL
XLCT-14-37 REACTION PAWL SPRING HEX LINK
XLCT-14-37 HX 14XLCT REAC PWL SPRING HEX
XLCT-14-37 SQ REACTION PAWL SPRING
XLCT-14-38 SQ REACTION PAWL SPRING ROLL PIN
XLCT-14-39 SQ REACTION PWL SPRING DOWEL PIN
XLCT-14-40 DISENGAGEMENT LEVER ASSY
XLCT-14-41 LEVER SCREW
XLCT-14-42 DRIVE PLATE STOP PIN
XLCT-14-43 1 SHROUD 2, 2-3/4, 50-70
XLCT-14-43 10 SHROUD 4-5/16 4-5/8, 111-120
XLCT-14-43 2 SHROUD 2-13/16 2-15/16, 71-75
XLCT-14-43 3 SHROUD 3, 3-1/8, 76-80
XLCT-14-43 4 SHROUD 3-3/16 3-3/8, 81-85
XLCT-14-43 5 SHROUD 3-7/16 3-1/2, 86-90
XLCT-14-43 6 SHROUD 3-9/16 3-3/4, 91-95
XLCT-14-43 7 SHROUD 3-13/16 3-7/8, 96-100
XLCT-14-43 8 SHROUD 3-15/16 4-1/8, 101-10
XLCT-14-43 9 SHROUD 4-3/16 4-1/4, 106-110
XLCT-14-43 SQ SHROUD
XLCT-14-44 HX SHROUD SCREW HEX LINK
XLCT-14-44 SQ SHROUD SCREW
XLCT-14-45 REACTION BLOCK SPACER
XLCT-14-45-C REACTION BLOCK SPACER EXTENDED
XLCT-14-46 TOP SPACER
XLCT-14-47 REACTION PAWL SPRING SPACER
XLCT-14-48 SIDE PLATE ROLL PIN
XLCT-14-49 SPRING SEAT
XLCT-14-50 SIDE PLATE SCREW BOTTOM
XLCT-14-51 SIDE PLATE SCREW TOP
XLCT-14-52L 1 S/PL LEFT 2, 2-3/4M 50-70
XLCT-14-52L 10 S/PL LEFT 4-5/16 4-5/8, 111-1
XLCT-14-52L 2 S/PL LEFT 2-13/16 2-15/16, 71
XLCT-14-52L 3 S/PL LEFT 3, 3-1/8, 76-80
XLCT-14-52L 4 S/PL LEFT 3-3/16 3-3/8, 81-85
XLCT-14-52L 5 S/PL LEFT 3-7/16 3-1/2, 86-90
XLCT-14-52L 6 S/PL LEFT 3-9/16 3-3/4, 91-95
XLCT-14-52L 7 S/PL LEFT 3-13/16 3-7/8, 96-1
XLCT-14-52L 8 S/PL LEFT 3-15/16 4-1/8, 101-
XLCT-14-52L 9 S/PL LEFT 4-3/16 4-1/4, 106-1
XLCT-14-52R 1 S/PL RIGHT 2, 2-3/4M 50-70
XLCT-14-52R 10 S/PL RIGHT 4-5/16 4-5/8, 111-
XLCT-14-52R 2 S/PL RIGHT 2-13/16 2-15/16, 7
XLCT-14-52R 3 S/PL RIGHT 3, 3-1/8, 76-80
XLCT-14-52R 4 S/PL RIGHT 3-3/16 3-3/8, 81-8
XLCT-14-52R 5 S/PL RIGHT 3-7/16 3-1/, 86-9
XLCT-14-52R 6 S/PL RIGHT 3-9/16 3-3/4, 91-9
XLCT-14-52R 7 S/PL RIGHT 3-13/16 3-7/8, 96-
XLCT-14-52R 8 S/PL RIGHT 3-15/16 4-1/8, 101
XLCT-14-52R 9 S/PL RIGHT 4-3/16 4-1/4, 106-
XLCT-14-60-C 14XLCT END CAP POST
XLCT-14-61-C 14XLCT SWIVEL POST
XLCT-14-62 UNISWIVEL ASSY 360X360
XLCT-14-63 UNISWIVEL 360X360 SEAL KIT
XLCT-14-65 14XLCT BUSH HOUSING


Y-NPL-XLCT NAME PLATE XLCT
Y-XLT-SF001 3-25XLT UNISWIVEL POST
Y-XLT-SF002 3-25XLT SWIV BLOCK
Y-XLT-SF003 3-25XLT SAFETY SHIELD


MK-HY-14XLCT 14XLCT MAINT KIT
MODEL 18XLCT
PART NUMBER DESCRIPTION
XLCT-18-01 18XLCT HOUSING
XLCT-18-02 18XLCT END CAP
XLCT-18-03 18XLCT PISTON
XLCT-18-04 18XLCT PISTON ROD
XLCT-18-05 18XLCT ROD END
XLCT-18-07 18XLCT CYL. END CAP SCR
XLCT-18-08 18XLCT FIXED PIN UPPER
XLCT-18-10 18XLCT LINK PIN SHORT
XLCT-18-11 18XLCT REACTION PAD PIN
XLCT-18-12 18XLCT LINK PIN RETAINER
XLCT-18-13 18XLCT SEAL KIT
XLCT-18-14 18XLCT LINK REACTION PAD
XLCT-18-22 18XLCT DRIVE PAWL PRIMA
XLCT-18-23 18XLCT DRIVE PAWL SECOND
XLCT-18-28 105MM 18XLCT RATCHET 105MM
XLCT-18-28 410 18XLCT RATCHET 4-5/8"
XLCT-18-28 71MM 18XLCT RATCHET 71MM
XLCT-18-28 85MM 18XLCT RATCHET LINK 85MM
XLCT-18-32 18XLCT SPRING SPACER RO
XLCT-18-33 18XLCT DRIVE PIN
XLCT-18-34 18XLCT DRIVE PIN SPRING
XLCT-18-36 10 REACTION PAWL KIT 4-5/8"
XLCT-18-37 18XLCT REACTION PAWL SP
XLCT-18-43 1 18XLCT SHROUD #1
XLCT-18-43 2 18XLCT SHROUD #2
XLCT-18-43 3 18XLCT SHROUD #3
XLCT-18-43 4 18XLCT SHROUD #4
XLCT-18-43 5 18XLCT SHROUD #5
XLCT-18-43 6 18XLCT SHROUD #6
XLCT-18-43 7 18XLCT SHROUD
XLCT-18-44 18XLCT SHROUD SCREW
XLCT-18-45 18XLCT REACTION BLOCK S
XLCT-18-46 18XLCT TOP SPACER
XLCT-18-47 18XLCT R/PAWL SPRING SP
XLCT-18-49 18XLCT D/PAWL SPRING SEC
XLCT-18-50 18XLCT S/PLATE SCREW BO
XLCT-18-51 SIDE PLATE SCREW
XLCT-18-52 L SIDE PLATE LEFT
XLCT-18-52 R 18 XLCT SIDE PLATE RIGHT


Y-NPL-XLCT NAME PLATE XLCT
Y-XLT-SF001 3-25XLT UNISWIVEL POST
Y-XLT-SF002 3-25XLT SWIV BLOCK
Y-XLT-SF003 3-25XLT SAFETY SHIELD
MODEL 30XLCT
PART NUMBER DESCRIPTION
XLCT-30-01 HOUSING
XLCT-30-02 END CAP
XLCT-30-03 PISTON
XLCT-30-04 PISTON ROD
XLCT-30-05 ROD END
XLCT-30-06 PISTON ROD ASSY
XLCT-30-07 CYLINDER END CAP SCREWS
XLCT-30-08 FIXED PIN UPPER
XLCT-30-09 FIXED PIN SET SCREW
XLCT-30-10 LINK PIN SHORT
XLCT-30-11 LINK PIN LONG
XLCT-30-12 LINK PIN RETAINER
XLCT-30-13 SEAL KIT
XLCT-30-14 HEX LINK REACTION PAD
XLCT-30-15 SQ. DR. HOUSING
XLCT-30-16 SQ. DR. REACTION ARM
XLCT-30-17 REACTION ARM SPLINE BUSHING
XLCT-30-18 SQ. DRIVE 3/4"
XLCT-30-19 SQ. DRIVE SET SCREW
XLCT-30-20 DRIVE RETAINER ASSY
XLCT-30-22 DRIVE PAWL PRIMARY
XLCT-30-23 DRIVE PAWL SECONDARY
XLCT-30-24 DRIVE PAWL SOCKET HEAD CAP SCR
XLCT-30-25 DRIVE PAWL LEAF SPRING
XLCT-30-26 LEAF SPRING SCREW
XLCT-30-27 DRIVE PAWL SPRING HEX LINK
XLCT-30-27 HX 30XLCT DRIVE PAWL SPG HEX
XLCT-30-28 100MM 100MM RATCHET
XLCT-30-28 105MM 105MM RATCHET
XLCT-30-28 110MM 110MM RATCHET
XLCT-30-28 115MM 115MM RATCHET
XLCT-30-28 120MM 120MM RATCHET
XLCT-30-28 125MM 125MM RATCHET
XLCT-30-28 130MM 130MM RATCHET
XLCT-30-28 135MM 135MM RATCHET
XLCT-30-28 140MM 140MM RATCHET
XLCT-30-28 145MM 145MM RATCHET
XLCT-30-28 150MM 150MM RATCHET
XLCT-30-28 155MM 155MM RATCHET
XLCT-30-28 208 RATCHET 2-1/2"
XLCT-30-28 212 RATCHET 2-3/4"
XLCT-30-28 215 RATCHET 2-15/16"
XLCT-30-28 302 RATCHET 3-1/8"
XLCT-30-28 304 X RATCHET 3-1/8"
XLCT-30-28 306 RATCHET 3-3/8"
XLCT-30-28 308 RATCHET 3-1/2"
XLCT-30-28 309 RATCHET 3-9/16"
XLCT-30-28 311 RATCHET 3-11/16"
XLCT-30-28 312 RATCHET 3-3/4"
XLCT-30-28 314 RATCHET 3-7/8"
XLCT-30-28 315 RATCHET 3-15/16"
XLCT-30-28 400 RATCHET 4"
XLCT-30-28 401 X RATCHET 4"
XLCT-30-28 402 RATCHET 4-1/8"
XLCT-30-28 404 X RATCHET 4-1/8"
XLCT-30-28 406 RATCHET 4-3/8"
XLCT-30-28 408 X RATCHET 4-3/8"
XLCT-30-28 410 RATCHET 4-5/8"
XLCT-30-28 500 RATCHET 5"
XLCT-30-28 506 RATCHET 5-3/8"
XLCT-30-28 508 RATCHET 5-1/2"
XLCT-30-28 512 X RATCHET 5-1/2"
XLCT-30-28 602 RATCHET 6-1/8"
XLCT-30-28 70MM 70MM RATCHET
XLCT-30-28 75MM 75MM RATCHET
XLCT-30-28 80MM 80MM RATCHET
XLCT-30-28 85MM 85MM RATCHET
XLCT-30-28 90MM 90MM RATCHET
XLCT-30-28 95MM 95MM RATCHET
XLCT-30-28 SQ SQ. DRIVE RATCHET
XLCT-30-29 RATCHET RETAINING PIN
XLCT-30-30 RATCHET RING ROLL PIN
XLCT-30-31 SPRING SPACER
XLCT-30-32 SPRING SPACER ROLL PIN
XLCT-30-33 DRIVE PIN
XLCT-30-34 DRIVE PIN SPRING
XLCT-30-35 SQ DRIVE PLATE SQ.
XLCT-30-35L 1 L/DR PL 2-1/2 3-1/2, 64-90
XLCT-30-35L 2 L/DR PL 3-9/16 3-7/8, 91-100
XLCT-30-35L 3 L/DR PL 3-15/16 4-1/4, 101-11
XLCT-30-35L 4 L/DR PL 4-5/16 4-5/8, 111-120
XLCT-30-35L 5 L/DR PL 4-11/16 5, 121-130
XLCT-30-35L 6 L/DR PL 5-1/16 5-3/8, 131-135
XLCT-30-35L 7 L/DR PL 5-7/16 5-3/4, 136-145
XLCT-30-35L 8 L/DR PL 5-13/16 6-1/8, 146-15
XLCT-30-35R 1 R/DR PL 2-1/2 3-1/2, 64-90"
XLCT-30-35R 2 R/DR PL 3-9/16 3-7/8, 91-100
XLCT-30-35R 3 R/DR PL 3-15/16 4-1/4, 101-11
XLCT-30-35R 4 R/DR PL 4-5/16 4-5/8, 111-120
XLCT-30-35R 5 R/DR PL 4-11/16 5, 121-130
XLCT-30-35R 6 R/DR PL 5-1/16 5-3/8, 131-135
XLCT-30-35R 7 R/DR PL 5-7/16 5-3/4, 136-145
XLCT-30-35R 8 R/DR PL 5-13/16 6-1/8, 146-15
XLCT-30-36 1 REAC. PAWL 2-1/2 3-1/2, 64-90
XLCT-30-36 2 REAC. PAWL 3-9/16 3-7/8, 91-1
XLCT-30-36 3 REAC. PAWL 3-15/16 4-1/4, 101
XLCT-30-36 4 REAC. PAWL 4-5/16 4-5/8, 111-
XLCT-30-36 5 REAC. PAWL 4-11/16 - 5, 121-1
XLCT-30-36 6 REAC. PAWL 5-1/16 5-3/8, 131-
XLCT-30-36 7 REAC. PAWL 5-7/16 5-3/4, 136-
XLCT-30-36 8 REAC. PAWL 5-13/16 6-1/8, 146
XLCT-30-36 SQ REACTION PAWL
XLCT-30-37 REACTION PAWL SPRING HEX LINK
XLCT-30-37 HX 30XLCT REAC PAWL SPR HEX
XLCT-30-37 SQ REACTION PAWL SPRING
XLCT-30-38 SQ REACTION PAWL SPRING ROLL PIN
XLCT-30-39 SQ REACTION PWL SPRING DOWEL PIN
XLCT-30-40 DISENGAGEMENT LEVEL ASSY
XLCT-30-41 LEVER SCREW
XLCT-30-42 DRIVE PLATE STOP PIN
XLCT-30-43 SHROUD
XLCT-30-43 1 SHROUD 2-1/2 3-1/2, 64-90
XLCT-30-43 2 SHROUD 3-9/16 3-7/8, 91-100
XLCT-30-43 3 SHROUD 3-15/16 4-1/4, 101-110
XLCT-30-43 4 SHROUD 4-5/16 4-5/8, 111-120
XLCT-30-43 5 SHROUD 4-11/16 - 5, 121-130
XLCT-30-43 6 SHROUD 5-1/16 5-3/8, 131-135
XLCT-30-43 7 SHROUD 5-7/16 5-3/4, 136-145
XLCT-30-43 8 SHROUD 5-13/16 6-1/8, 146-155
XLCT-30-44 SHROUD SCREW
XLCT-30-44 HX SHROUD SCREW HEX LINK
XLCT-30-45 REACTION BLOCK SPACER
XLCT-30-46 TOP SPACER
XLCT-30-47 REACTION PAWL SPRING SPACER
XLCT-30-48 SIDE PLATE ROLL PIN
XLCT-30-49 SPRING SEAT
XLCT-30-50 SIDE PLATE SCREW BOTTOM
XLCT-30-51 SIDE PLATE SCREW TOP
XLCT-30-52L 1 L/DR PL 2-1/2 3-1/2, 64-90
XLCT-30-52L 2 L/DR PL 3-9/16 3-7/8, 91-100
XLCT-30-52L 3 L/DR PL 3-15/16 4-1/4, 101-11
XLCT-30-52L 4 L/DR PL 4-5/16 4-5/8, 111-120
XLCT-30-52L 5 L/DR PL 4-11/16 5, 121-130
XLCT-30-52L 6 L/DR PL 5-1/16 5-3/8, 131-135
XLCT-30-52L 7 L/DR PL 5-7/16 5-3/4, 136-145
XLCT-30-52L 8 L/DR PL 5-13/16 6-1/8, 146-15
XLCT-30-52R 1 R/DR PL 2-1/2 3-1/2, 64-90"
XLCT-30-52R 2 R/DR PL 3-9/16 3-7/8, 91-100
XLCT-30-52R 3 R/DR PL 3-15/16 4-1/4, 101-11
XLCT-30-52R 4 R/DR PL 4-5/16 4-5/8, 111-120
XLCT-30-52R 5 R/DR PL 4-11/16 5, 121-130
XLCT-30-52R 6 R/DR PL 5-1/16 5-3/8, 131-135
XLCT-30-52R 7 R/DR PL 5-7/16 5-3/4, 136-145
XLCT-30-52R 8 R/DR PL 5-13/16 6-1/8, 146-15


Y-NPL-XLCT NAME PLATE XLCT
Y-XLT-SF001 3-25XLT UNISWIVEL POST
Y-XLT-SF002 3-25XLT SWIV BLOCK
Y-XLT-SF003 3-25XLT SAFETY SHIELD
